648AA 钻井平台补给管 软壁 - 燃油 – 液态泥浆 20 bar

648AA 钻井平台补给管 软壁 - 燃油 – 液态泥浆 20 bar

Tube: black conductive NBR.
Reinforcement: high tensile textile cords - antistatic wire.
Cover: black conductive CR - abrasion, ozone, hydrocarbon and fire resistant.
Application: fuel, oil and liquid mud transfer from supply vessels to offshore platforms.
Also suitable for sea water pumping and barite transfer. Specially designed for reeling applications and weak linkcouplings use.
Tensile end load resistance:
ID 2"  2.000 kg
ID 3"  4.000 kg
ID 4"   7.000 kg
ID ≥ 5"  10.000 kg
ABS Type approved hose assemblies.
Electrically continuous.
Constant operation: -30 °C +90 °C (-22 °F +194 °F)


内胶层: 黑色导电NBR
加强层: 高强度纤维线-防静电线
外胶层: 黑色导电CR –耐磨损、耐臭氧、耐烃类化合物和耐火
应用: 将燃油和液态泥浆从平台补给船输送到海工平台，也适用于海水泵送和散装物料的输送
抗拉强度:
ID 2"   2.000 kg
ID 3"   4.000 kg
ID 4"   7.000 kg
ID ≥ 5" 10.000 kg
软管总成可具备ABS船级社产品证书
连续导电
常规运行温度范围: -30 °C +90 °C (-22 °F +194 °F)
品牌字样：ALFAGOMMA -ITALY- T-648 20 BAR (300 PSI) HD PETROLEUM & LIQUID MUD SOFT WALL (omega) - RIG SUPPLY - DNV N° P-11128
